DCA 435 Double Head Aluminium & PVC Cutting Machine
SCHTEC DCA 435: Fully automatic aluminum cutting, 0.1 mm precision, 45°-135° angles, 6.5m length, 550 mm blades, Beckhoff software for efficient production.
DCA 435 Technical Specifications
| Power Supply | 400 V, 3 Ph, 50-60 Hz |
| Total Power | 7.2 kW |
| Power Output of Each Motor | 3 kW |
| Diameter of Saw Blade | 550 mm |
| Saw Blade Speed | 2,800 rpm |
| Cutting Length | 250 mm - 6,500 mm |
| Air Pressure | 6-8 bar |
| Air Consumption | 60 l/min |
| Machine Height | 1,935 mm |
| Machine Length | 8,100 mm |
| Machine Width | 1,950 mm |
| Machine Weight | 2,650 kg |
DCA 435 Automatic Double Head Aluminium Cutting Machine
Standard Features
- Cutting of Aluminum profiles with high speed and precision thanks to 3-axis servo system
- Strong construction, lineer rail and sliding-bearing system for precise length and angle
- Industrial PC Based Servo Control System, 10 touch screen (Beckhoff)
- Ethercat based controlled drivers and high-torque servo motors
- Remote desktop connection by way of Wifi or Network connection
- File transfer via USB or Network
- Central lubrication system
- All error messages can be seen on the machine screen with the interface program which developed by SCHTEC Software R&D Department.
- Remote connection method and problem detection and solution by connecting to all automation system
- High angle accuracy thanks to cycloid gap free gearbox
- Profile height automatically transferred from profile data
- Automatic aluminum corner block cutting
- Cooling system to cut Aluminium profiles
- Hydro-pneumatic system to cut Aluminium profiles
- The saw heads tilt automatically between 45° and 135° by servo motors
- Machine can make single cuts
- Adjustable saw cutting speed
- Profile support conveyor is available on the machine as standard
Optional
- Barcode printer system
The SCHTEC DCA 435 is a fully automatic double-head aluminum processing machine designed for precise angular operations between 45° and 135°. Equipped with a 550 mm saw blade and a servo-assisted 3-axis system, it operates with high speed and stability, even on large profiles. Its hydro-pneumatic drive enhances processing quality while minimizing maintenance needs. With a capacity of up to 6.5 meters, a user-friendly interface based on Beckhoff, and Schtec software, it offers efficiency and precision in production.
