RC 210 Copy Router Machine with the Triple Drill
Schtec RC 210: Precision copy router for PVC & aluminum profiles, 0.75 kW motor, 12,000 rpm, 1:1 template processing, pneumatic clamping. Compact, user-friendly for workshops.
RC 210 Technical Specifications
| Power Supply | 400 V, 3 Ph, 50-60 Hz |
| Power Output (Router) | 0.75 kW |
| Router Spindle Speed | 12,000 rpm |
| Routing Capacity | 120 × 250 mm |
| Air Pressure | 6-8 bar |
| Air Consumption | 5 l/min |
| Machine Height | 1,470 mm |
| Machine Length | 1,050 mm |
| Machine Width | 720 mm |
| Machine Weight | 125 kg |
Description
RC 210 Copy Router Machine with the Triple Drill
Standard Features
- Opens tilt system channel, drain slot, lock cylinders and door handle holes on PVC and Aluminium profiles
- 1:1 ratio pattern transfer onto a profile from a template
- Milling process is done by a high speed frequency controlled motor
- Milling with adjustable measurement apparatus without using a template
- Using 2 different size (5mm-8mm) bits on single template with 2 different step.
- Pneumatic Profile Clamping
- Left and right measurement centering system
Optional
- Cooling system for aluminium profiles
The Schtec RC 210 is an efficient machine designed for copy routing and manual triple drilling on PVC profiles. Its 0.75 kW motor operates at 12,000 rpm for 1:1 template milling, while the 1.1 kW drilling motor is used for handle slots. Equipped with 5–8 mm guides, adjustable stops, and a pneumatic clamping system, it ensures safe and flexible operation. With a compact design and 160 kg weight, the RC 210 is exported to over 65 countries under Schtec quality.
